RF Distribution Accessory SC2510
8- PORT LO DISTRIBUTION MODULE
The SignalCraft SC2510 RF Distribution Module is a high-performance, active 8-way RF splitter engineered for applications requiring phase coherence, high isolation, and net 0 dB gain.
-
Overview
-
Overview
The SignalCraft SC2510 RF Distribution Module is a high-performance, active 8-way RF splitter engineered for applications requiring phase coherence, high isolation, and net 0 dB gain with a frequency range of 500 MHz – 8 GHz. It ensures consistent signal strength across all output ports while maintaining phase stability, making it ideal for LO (Local Oscillator) distribution in MIMO systems, aerospace and defense test setups, and other software defined radio (SDR) applications.
With its high port-to-port isolation, this active splitter eliminates signal interference, ensuring accurate and repeatable results. Whether you’re working on wireless communication systems, phased array antennas, or test and measurement setups, this 8-way RF splitter delivers uncompromising performance and reliable signal integrity.
Note for use with the USRP X420: the USRP X420 LO distribution supports a maximum input frequency of 6 GHz and is internally multiplied to support up to 20 GHz.
Typical Applications
- Phase-Coherent Systems
- Multi-Channel Radar Test
- Software Defined Radio
- Advanced Wireless Communications Research
-
Block Diagram
-
Block Diagram
RF Distribution Accessory Block Diagram
Click on image to enlarge
RF Distribution Accessory Block Diagram
-
Additional Resources
-
Additional Resources
The following resources are available from SignalCraft (a free account is required):
- Getting Started Guide
- Product Specification
- Declaration of Conformity
The following accessories and mounting hardware are also available from SignalCraft:
- SC2430-54: UHD GPIO Cable (0.2 m, vertical configuration)
- SC2430-55: UHD GPIO Cable (0.2 m, horizontal configuration)
- SC2430-71: Mounting Plate with Handle for SC24xx
- SC2430-61: SMA (m) to SMA (m) cable, 75mm
- SC2430-73: 5-Up Side Rail Mounting Kit with Handle
